Re: CF Images for the Dual IDE/CF

Harold -

An older image I had at work is appended, I believe it's still the same as my setup at home.

The CP/M files are near the bottom of this page:

http://s100computers.com/Software%20Folder/CPM3%20BIOS%20Installation/CPM3%20HDISK%20BIOS%20Software.htm

Making CPM disk images.pdf
CPM3-2014-06-27(1).ZIP

If you can't locate the images, I can dupe the CF card for you here.

- Gary

On Tuesday, June 30, 2015 at 9:35:25 AM UTC-4, hlr...@gmail.com wrote:

Hi Everyone.

I have been building up a system with the Z80 board, 4MB memory board, Dual IDE/CF, and the prop I/O. I have finished this and am using the V5.02 ROM on the Z80. The system boots up to the menu. However I can't do very much except check memory and display.

Now I want use my V2 Dual IDE/CF to boot up CP/M. Unfortunately the link on s100computers for the jumper and switch setup is not working! I was wondering what people use for settings on SW1, SW2. I think I have jumpers K1 and K5 set okay.

I also found a thread about CF images for the IDE/CF board, but the date was several years ago. Is there a location where I can copy a disk image for CP/M? I have the Kingston 4GB CF.

Any help would be great!

Thanks
Harold
